750W ANTEC ATOM G750 BRAND NEW POWER SUPPLY

Key Specifications

• Total Power Output: 750W Continuous Power

• Efficiency Certification: 80 PLUS® Gold (Up to ~90% energy efficiency under typical load)

• Design / Cable Type: Semi-Modular / Flat Black Cables

• Topology: DC-to-DC Module design with Active Power Factor Correction (APFC)

• Form Factor: ATX 12V v2.4 / Standard ATX

• Cooling: 120mm Silent Fan with Thermal Manager (automated fan speed control for noise and heat management)

• Warranty: 3 to 5 Years (varies by regional distributor/retailer)

Typical Connector Layout

• 1x 24 (20+4)-Pin Main Motherboard

• 2x 8 (4+4)-Pin CPU / EPS 12V

• 4x 8 (6+2)-Pin PCIe (Graphics Cards)

• 6x SATA Connectors

• 3x 4-Pin Molex / Peripheral Connectors

Protection Features (CircuitShield™)

Includes comprehensive industrial-grade protection features to keep your hardware safe:

• OVP (Over Voltage Protection)

• UVP (Under Voltage Protection)

• OCP (Over Current Protection)

• OPP (Over Power Protection)

• SCP (Short Circuit Protection)

• OTP (Over Temperature Protection)

• NLO (No Load Operation)

Best Suited For

• Mid-range to upper-mid tier gaming builds equipped with power-demanding GPUs (e.g., NVIDIA RTX 4070 / 4070 Ti, AMD Radeon RX 7700 XT / 7800 XT) paired with multi-core CPUs.
